Material:
Main Frame: Steel with Powder Coated Finish
Bed platform: ABS
Head & tail boards: ABS
Alum. side rails(Round Stainless Steel supporting tubes)

Functions:
Adj. Hi-Lo: 260mm±3%
Adj. head platform to 85°
Adj. tail platform to 40°

Standard Equipment:
Two Side rail Controllers with double side
Control board 5" castors W / brake
(Anti-dust & Anti-static)
Controller by LINAK

Optional Equipment:
Head & tail boards surface decoration
(Available in Various Colours)
Under Bed Storage Basket
Hidden E.R. board
Centeral Control Brake System on all Four Castors
Trenelenburg / Reverse Trenelenburg to the Maximum of 11°

Controller System Specification:
Tail Motor: LA31.2-150-L1-002
Max. Output: 200KG
Voltage: DC 24V, 3.8A
Head Motor: LA31.2-200-L1-002
Max. Output: 200KG
Voltage: DC 24V, 3.8A
Elevating Motor: LA31.2-200-L1-002
Max. Output: 200KG
Voltage: DC 24V, 3.8A
Input Voltage: (AC 120V input) 5% 60HZ
Operating Volage: DC 24V, 5.8A
Operating Periodicity:
Max 10% or 6 minutes of continuously usage per Hour.
